LIVING AREA = 640 SQ FT
COVERED PORCH AREA = 74 SQ FT
TOTAL BUILDING AREA = 714 SQ FT
DEPTH = 37'-6" ( 32'-0" + 5'-6" PORCH )
WIDTH = 20'-0"
1 LEVEL / FLOOR
ROOF & CEILING
MANUFACTURED ROOF TRUSSES
SLAB ON GRADE
2X6 EXTERIOR WALLS
2X4 INTERIOR WALLS
COVERED FRONT PORCH
Plan 20-104.6 (640 Sq Ft - 1Bed/1Bath)
The type of download you need is depenent upon your specific needs. Please read our short desciption for each download option so that you can best decide which download option is right for you!
Each set of construction drawings include a detailed foundation plan, dimensioned floor plan, structural bracing calcs, a detailed roof plan, electrical/mechanical plan, exterior elevations, and construction details applicaple to each specific plan.
PDF Set - Downloadable PDF file of the full-size construction drawings. This file can be emailed to contractors for bidding, and/or easily printed in 24"x36" format and turned in for permitting and construction. If you intend to modify the plan with a local architect or designer, we recommend purchasing the CAD Set as these are more easily manipulated.
CAD Set - Downloadable CAD file of the full-size construction drawings. This download is best for those intending to have a local architect or designer modify the plans to their specific needs. This set comes in Autocad version 2018 .dwg format and can be altered and/or scaled to any size desired.
